alligator clip set, 2 pieces TP40 • 12" cable assembly, unshielded RJ45
connectors, 2 pieces TP56 • 7.5" cable assembly with no-fault RJ12
connectors for RJ11 and RJ45 jacks, 2 pieces TP20 • Pouch PC150
Identifies telephone and
data lines.
• Identifies 10Base-T, Token Ring
and 100Mbit Systems
• Includes a built-in battery
• Detects voltage and polarity
Tell-All Accessories
TP10 Replacement jumper cable
includes standard RJ45 on one
end and unique modular plug
on the other end that works
with both RJ11 and RJ45 jacks
TP56 12" cable assembly,
unshielded, RJ45 connectors
TP20 7.5" cable assembly with no fault
RJ12 connectors for RJ11 or
RJ45 jacks. The connectors assure
no damage to RJ45 jacks.
TP40 12" cable assembly, RJ45 to
alligator clip set
TP50 Adapter, RJ45 to F coax, 1 piece
TP55 12" cable assembly, shielded,
RJ45 connectors
TP56 12" cable assembly, unshielded,
RJ45 connectors
TP60 Adapter, RJ45 plug/RJ11 jack,
2 pieces
TP608 Set of 7 network remote
identifiers (#2–#8)
TP609 #1 replacement remote
identifier
PC400 Carrying case, holds one
LanScaper™ or LanRoverPRO™ Kit
with remotes
NT750 Includes:
• LanScaper™
• Remotes #1–#8
• Tone tracer TT100
• 12" cable assembly,
RJ45 to alligator
clip set, 2 pieces TP40
• 12" cable assembly, unshielded RJ45
connectors, 2 pieces TP56
• RJ45 to F connector, 2 pieces TP50
• 7.5" cable assembly with no-fault
RJ12 connectors for RJ11 and RJ45
jacks, 9 pieces TP20
• Carrying case PC400
LanScaper™ Network Tester NT700
The first in a new line of Physical Layer Network Management Devices, the LanScaper™ combines the functions of a high-end cable tester and length measurement device with the capability to monitor and correct network problems connected with the physical layer and link conditions of the network.
• Identifies port services including Ethernet, ISDN, POTS, and Token-Ring while
reporting such crucial information as network speed, capability, and location
of other network devices
• Pinging function verifies connectivity to network devices and queries PC/NICs
• Detects legacy “Phantom Power”, reports current and voltage capability of
analog telephone lines, identifies (maps) remotes while cable testing
• Conducts link tests to ID speed
• Verifies functional speed capability of terminated unconnected cable runs by
sampling data packets between two LanScaper™ units, which exercises the
run and reports the result
• Automatically accesses DHCP host and obtains network information
• Tests cabling configuration and verifies connectivity and length of run while
conducting tests for opens, shorts, miswires, split pairs, and reversals
• Identifies HUBs, NIC, or auto MDI/MDI-X devices
• Blinks HUBs to ascertain connected configuration
• Displays advertised network speed/duplex
• Measures and reports any voltage on lines
• Wiremaps network connections with remote identifiers
• Generates multiple tone levels for signal tracing and cable identification
Kit with
8 remote
identifiers
TP607 Includes:
• LanRoverPRO™
• Remotes #1–#8
• 12" cable assembly,
RJ45 to alligator clip set TP40
• RJ45 to coax adapter, 2 pieces TP50
• 12" cable assembly, unshielded
RJ45 connectors, 2 pieces TP56
• Wire configuration sticker
• Laminated quick reference card
• Carrying case PC400
Associated Kits
with LanRover™ are on pages 17–19.
Kit numbers: KP500, KP600, KP605-A.
Accessory
TP505 LanRover™ #1 replacement remote
TP500 includes: • LanRover™ • Remote #1 • 12" cable assembly, unshielded
RJ45 connectors, 2 pieces TP56 • Pouch PC150
LanRover™ Tester/Analyzer TP500
Offers a new price/performance level for verification of wiring faults
and configurations on all your data cable.
• Cable test results displayed on main unit and remote unit in less than
2 seconds after plugging in the cable
• Auto-on and auto-off—when testing cables, just plug both ends into tester!
• Snap-together case for easy storage and convenient patch cable testing
• Tone generator mode for use with tone tracers, auto-off
• Debug mode with from/to and failures for each pair
• Test for short, opens, miswires,
LanRover™/LanRoverPRO™Accessories
TP40 12" cable assembly, RJ45 to alligator clip set
TP50 Adapter, RJ45 to F coax, 1 piece
TP55 12" cable assembly, shielded, RJ45 connectors
TP56 12" cable assembly, unshielded, RJ45 connectors
TP60 Adapter, RJ45 plug/RJ11 jack, 2 pieces
TP62 Adapter, F plug to BNC jack
LB32 24" cable assembly, “F” push-on plug to alligator clip set
LB34 18" cable assembly, “F” push-on plug to RJ11 plug
PC400 Carrying case, holds one LanScaper™ or LanRoverPRO™ Kit with remotes
TP608 Set of 7 network remote identifiers (#2–#8)
TP609 #1 replacement remote identifier
Associated Kits with LanRoverPRO™ are on pages 17–19.
Kit numbers: KP450, KP501, KP506-A, KP601, KP602-A.
RJ45 to alligator clip set TP40 • 12" cable assembly, unshielded RJ45
connectors, 2 pieces TP56 • Wire configuration sticker • Laminated
quick reference card • Pouch PC150
LanRoverPRO™ Tester/Analyzer TP600
This high-performance length measurement CAT 5/6 tester identifies multiple faults clearly without interpretation for fast results; clear wire mapping form displayed on 2-line, 16-character LCD display; and measures cable length.
• Measures cable length as a stand-alone function
• Test for short, opens, miswires, reversals, and split pairs
• Identifies multiple faults clearly without interpretation
• Clear wiremapping form displayed in 2-line, 16-character LCD display
• Auto-off/Auto-on—Up to 10 times better battery life than other testers
• One-ended testing with Pre-test mode for fast results
• Built-in tone generator with selectable tones and pair capability
UAE +971 2 5557351 +971 4 3352995 +971 4 8831401 OMAN +968 24 750205 QATAR +974 44150543
#1 coax remote
identifier
TP309 Replacement
#1 remote identifier
TP312 Set of 20 RJ45 wiremappers
TP314 Set of 20 RJ11 wiremappers
TP608 Set of 7 network remote
identifiers (#2–#8)
PC400 Carrying case for Resi-Tester™
and remotes
This signal strength meter is a simple mechanical
device used to maximize a satellite signal between
the LNB amplifier and the receiver.
• The CS300 is easy to use and very inexpensive
• Perfect for installing and setting up direct
satellite systems
• Packaged in a clear-view hang-up clamshell
• Less money than most competitive models available
• Rugged ABS body
• Easy-to-read analog display
• Frequency Range: 950 MHz–2,050 MHz
• Variable attenuator for ultra-fine tuning capability
• Powered by satellite receiver, no batteries required
Designed for testing CATV and security camera coax
connections and installations.
• Finds and identifies multiple coax cables
• Includes 4 color-coded F-connectors and BNC adapters
• Built-in tone generator
Coax Mapper Accessories
CX31 Replacement #1 brown terminator
CX32 Replacement #2 red terminator
CX33 Replacement #3 orange terminator
CX34 Replacement #4 yellow terminator
LB34 18" cable assembly, “F” push-on plug to RJ11 plug
TP20 7.5" cable assembly, with no-fault RJ12
connectors for RJ11 or RJ45 jacks.
TP40 12" cable assembly, RJ45 to alligator clip set.
TP68 24" cable assembly, RJ45 with 8 alligator clips
for use on multiple unterminated cables
TP310 Set of 10 (1–10) coax remote identifiers
• #1 coax remote identifier TP65 • 12" cable assembly, RJ45 to alligator
clip set TP40 • 7.5" cable assembly with no-fault RJ12 connectors for
RJ11 or RJ45 jacks TP20
Resi-Tester™ Whole-House Cable Tester TP300
The first identifier and verification tester designed exclusively for all the wiring environments found in Home Networking and Home Automation. CATV, telephone systems, audio cable, security/alarm wiring, and network cabling can all be tested and located using the Resi-Tester™ and optional room identifier sets. Multiple input ports and included adapter cables mean any wire can be attached and tested!
A large, easy-to-read LCD displays cabling results using clear, concise information, showing all the faults connected with the various cable types. It warns of voltage on lines and shows a Pass or Fail message after each test.
The built-in tone generator sends a signal down installed wires, so that they can be traced in the walls, with the exact terminus identified. The built-in remote identifies individual outlets whether they are phone, cable, or data network. Using the optional multi-identifier sets, the user can wiremap connections on up to 20 coax outlets and 20 paired cables simultaneously, for wire-mapping the largest jobs easily and efficiently.
