Type of SPD

T1,T2

Mounting

DIN rail 35 mm

Nominal voltage

U_n

230 V AC

Maximum operating voltage L-N

U_c

275.00 V AC

Maximum operating voltage N-PE

U_c

255.00 V AC

Type of network

TT

Maximum overcurrent protection

160 A gL/gG

Short-circuit current rating

I_SCCR

50.0 kA

Lightning impulse current (10/350 µs) L-N

I_imp

12.50 kA

Lightning impulse current (10/350 µs) N-PE

I_imp

25.00 kA

Nominal discharge current (8/20 µs) L-N

I_n

30.00 kA

Nominal discharge current (8/20 µs) N-PE

I_n

30.00 kA

Maximum discharge current (8/20 µs) L-N

I_max

60.00 kA

Maximum discharge current (8/20 µs) N-PE

I_max

60.00 kA

Voltage protection level mode L-N

U_p

1.50 kV

Voltage protection level mode N-PE

U_p

1.50 kV

Response time L-N

t_a

100 ns

Response time N-PE

t_a

100 ns

TOV 5 s L-N

335 V

TOV characteristic (TOV 5 s)

withstand

TOV 120 min L-N

440 V

TOV characteristic (120 min)

withstand

TOV 200 ms N-PE

1 200 V

TOV characteristic (TOV 200 ms)

withstand

Cross-section of connected conductors solid (min)

1.00 mm²

Cross-section of connected conductors solid (max)

35.00 mm²

Cross-section of connected conductors stranded (min)

1.00 mm²

Cross-section of connected conductors stranded (max)

25.00 mm²

Cross-section of remote indication conductors solid (max)

1.5 mm²

Cross-section of remote indication conductors stranded (max)

1.5 mm²

Fault indication L-N

red indication field

Fault indication N-PE

no

Remote indication

potential-free change-over contact

Remote indication contacts

250V/0,5A AC,250V/0,1A DC

Degree of protection

IP 20

Range of ambient temperatures (min/max)

-40 / 80 °C

Humidity

5 - 95 %

According to standard

EN 61643-11:2012, IEC 61643-11:2011

ETIM Class

EC001457

Plug module

FLP-12,5-VBH/0

Customs tariff number

85363030

EAN

8595090570431
