Type of SPD

T1

Mounting

DIN rail 35 mm

Nominal voltage

U_n

230 V AC

Maximum operating voltage L-N

U_c

260.00 V AC

Maximum operating voltage N-PE

U_c

255.00 V AC

Nominal load current for "V" connection

I_L

125 A

Type of network

TT

Maximum overcurrent protection

250 A gL/gG

Maximum overcurrent protection for "V" connection

125 A gL/gG

Short-circuit current rating

I_SCCR

50.0 kA

Total discharge current (10/350 µs)

I_{Total(10/350)}

50.00 kA

Lightning impulse current (10/350 µs) L-N

I_imp

25.00 kA

Lightning impulse current (10/350 µs) N-PE

I_imp

50.00 kA

Voltage protection level mode L-N

U_p

1.50 kV

Voltage protection level mode L-PE

U_p

2.20 kV

Voltage protection level mode N-PE

U_p

1.50 kV

Ability to independently switch off the following current N-PE

I_fi

0.1 kA

Response time L-N

t_a

100 ns

Response time N-PE

t_a

100 ns

TOV 5 s L-N

335 V

TOV characteristic (TOV 5 s)

withstand

TOV 200 ms N-PE

1 200 V

TOV characteristic (TOV 200 ms)

withstand

Cross-section of connected conductors solid (min)

2.50 mm²

Cross-section of connected conductors solid (max)

50.00 mm²

Cross-section of connected conductors stranded (min)

2.50 mm²

Cross-section of connected conductors stranded (max)

35.00 mm²

Cross-section of remote indication conductors solid (max)

1.5 mm²

Cross-section of remote indication conductors stranded (max)

1.5 mm²

Fault indication L-N

red indication field

Fault indication N-PE

no

Remote indication

potential-free change-over contact

Remote indication contacts

250V/0,5A AC,250V/0,1A DC

Degree of protection

IP 20

Range of ambient temperatures (min/max)

-40 / 80 °C

Humidity

5 - 95 %

According to standard

EN 61643-11:2012, IEC 61643-11:2011

ETIM Class

EC000381

Plug module

FLP-25-T1-V/0|FLP-A50N V/0

Customs tariff number

85363090

EAN

8595090562580
