Type of SPD

T1,T2,T3

Mounting

40 mm busbar system

Nominal voltage

U_n

230 V AC

Maximum operating voltage

U_c

255.00 V AC

Type of network

TN

Maximum overcurrent protection

160 A gL/gG

Short-circuit current rating

I_SCCR

25.0 kA

Total discharge current (10/350 µs)

I_{Total(10/350)}

22.50 kA

Lightning impulse current (10/350 µs)

I_imp

7.50 kA

Nominal discharge current (8/20 µs)

I_n

20.00 kA

Test voltage

U_oc

10.0 kV

Total discharge current (8/20 µs)

I_Total(8/20)

100.00 kA

Maximum discharge current (8/20 µs)

I_max

60.00 kA

Voltage protection level

U_p

1.50 kV

Response time

t_a

100 ns

TOV 5 s L-N

335 V

TOV characteristic (TOV 5 s)

withstand

TOV 120 min L-N

440 V

TOV characteristic (120 min)

withstand

Cross-section of connected conductors solid (min)

1.00 mm²

Cross-section of connected conductors solid (max)

35.00 mm²

Cross-section of connected conductors stranded (min)

1.00 mm²

Cross-section of connected conductors stranded (max)

25.00 mm²

Cross-section of remote indication conductors solid (max)

1.5 mm²

Cross-section of remote indication conductors stranded (max)

1.5 mm²

Fault indication

red indication field

Remote indication

potential-free change-over contact

Remote indication contacts

250V/0,5A AC,250V/0,1A DC

Degree of protection

IP 20

Range of ambient temperatures (min/max)

-40 / 80 °C

Humidity

5 - 95 %

According to standard

EN 61643-11:2012, IEC 61643-11:2011

ETIM Class

EC000381

Plug module

FLP-ZP-7,5-VBH/0

Customs tariff number

85363090

EAN

8595090566229
