Type of SPD

T3

Mounting

DIN rail 35 mm

Nominal voltage

U_n

230 V AC

Maximum operating voltage L-N

U_c

275.00 V AC

Maximum operating voltage N-PE

U_c

255.00 V AC

Type of network

TT

Maximum overcurrent protection

63 A gL/gG

Short-circuit current rating

I_SCCR

25.0 kA

Nominal discharge current (8/20 µs) L-N

I_n

5.00 kA

Nominal discharge current (8/20 µs) N-PE

I_n

10.00 kA

Test voltage L-N

U_oc

10.0 kV

Test voltage N-PE

U_oc

20.0 kV

Voltage protection level mode L-N

U_p

1.00 kV

Voltage protection level mode L-PE

U_p

1.50 kV

Voltage protection level mode N-PE

U_p

1.50 kV

Response time

t_a

25 ns

Response time L-N

t_a

25 ns

Response time N-PE

t_a

100 ns

TOV 5 s L-N

335 V

TOV characteristic (TOV 5 s)

withstand

TOV 120 min L-N

440 V

TOV characteristic (120 min)

safe failure

TOV 200 ms L-PE

1 455 V

TOV 200 ms N-PE

1 200 V

TOV characteristic (TOV 200 ms)

safe failure

Cross-section of connected conductors solid (min)

1.00 mm²

Cross-section of connected conductors solid (max)

35.00 mm²

Cross-section of connected conductors stranded (min)

1.00 mm²

Cross-section of connected conductors stranded (max)

25.00 mm²

Fault indication L-N

red indication field

Fault indication N-PE

no

Degree of protection

IP 20

Range of ambient temperatures (min/max)

-40 / 80 °C

Humidity

5 - 95 %

According to standard

EN 61643-11:2012, IEC 61643-11:2011

ETIM Class

EC000942

Customs tariff number

85363030

EAN

8595090518488
