Type of SPD

T1,T2,T3

Maximum operating voltage

U_c

255.00 V AC

Short-circuit current rating

I_SCCR

25.0 kA

Lightning impulse current (10/350 µs)

I_imp

12.50 kA

Nominal discharge current (8/20 µs)

I_n

20.00 kA

Maximum discharge current (8/20 µs)

I_max

60.00 kA

Test voltage

U_oc

10.0 kV

Voltage protection level

U_p

1.50 kV

Response time

t_a

100 ns

Fault indication

red indication field

According to standard

EN 61643-11:2012, IEC 61643-11:2011

ETIM Class

EC000941

Customs tariff number

85363090

EAN

8595090566304
