Type of SPD

T3

Mounting

19" rack

Nominal voltage

U_n

230 V AC

Maximum operating voltage

U_c

275.00 V AC

Nominal load current

I_L

16.000 A

Type of network

TN

Maximum overcurrent protection

16 A gL/gG or C 16 A

Short-circuit current rating

I_SCCR

6.0 kA

Residual current

I_PE

0.004 mA

Nominal discharge current (8/20 µs) L-N

I_n

3.00 kA

Nominal discharge current (8/20 µs) L+N-PE

I_n

5.00 kA

Nominal discharge current (8/20 µs) N-PE

I_n

3.00 kA

Test voltage L-N

U_oc

6.0 kV

Test voltage N-PE

U_oc

6.0 kV

Test voltage L+N-PE

U_oc

10.0 kV

Voltage protection level mode L-N

U_p

1.20 kV

Voltage protection level mode L-PE

U_p

1.50 kV

Voltage protection level mode N-PE

U_p

1.50 kV

Response time L-N

t_a

25 ns

Response time N-PE

t_a

100 ns

Fault indication

red indicator

Degree of protection

IP 40

According to standard

EN 61643-11:2012, IEC 61643-11:2011

ETIM Class

EC000942

Customs tariff number

85363010

EAN

8595090562559
