• Replacement module for FLP-PV1000 V/Y
  • Replacement module for FLP-PV1000 V/Y


Specifications:

Parameter name

Parameter value

Maximum operating voltage

Uc

500.00 V DC

Short-circuit current rating

ISCPV

125 A DC

Lightning impulse current (10/350 µs)

Iimp

12.50 kA

Nominal discharge current (8/20 µs)

In

30.00 kA

Maximum discharge current (8/20 µs)

Imax

60.00 kA

Response time

ta

25 ns

Fault indication

red indication field

ETIM Class

EC000941

Customs tariff number

85363090

EAN

8595090542117


Dimensions:


Datasheet:

     FLP-PV500Y V/0
