Fault signalling
by supply interruption.
- Surge
protection especially for LED lights.
- Installation
close to protected equipment in LV power circuits.
- Also for equipment in external part of building with low exposure level (according to IEEE C62.41.2).
Specifications:
Parameter name |
Parameter
value |
|
|
Type of SPD |
T3 |
|
|
Mounting |
installation
box |
|
|
Nominal voltage |
Un |
230
V AC |
|
Maximum operating voltage |
Uc |
320.00
V AC |
|
Nominal load current |
IL |
5.000
A |
|
Maximum overcurrent protection |
B
16 A |
|
|
Short-circuit current rating |
ISCCR |
1.5
kA |
|
Nominal discharge current (8/20 µs)
L-N |
In |
3.00
kA |
|
Nominal discharge current (8/20 µs)
L+N-PE |
In |
5.00
kA |
|
Nominal discharge current (8/20 µs)
N-PE |
In |
3.00
kA |
|
Test voltage L-N |
Uoc |
6.0
kV |
|
Test voltage L+N-PE |
Uoc |
10.0
kV |
|
Test voltage L-PE |
Uoc |
6.0
kV |
|
Test voltage N-PE |
Uoc |
6.0
kV |
|
Voltage protection level mode L-N |
Up |
1.50
kV |
|
Voltage protection level mode L-PE |
Up |
1.50
kV |
|
Voltage protection level mode N-PE |
Up |
1.50
kV |
|
Response time L-N |
ta |
25
ns |
|
Response time N-PE |
ta |
100
ns |
|
Fault indication |
loss
of voltage |
|
|
Remote indication |
potential
open contact |
|
|
Maximum current of signalling |
1.00
A |
|
|
Degree of protection |
IP
20 |
|
|
Range of ambient temperatures
(min/max) |
-40
/ 80 °C |
|
|
Humidity |
5
- 95 % |
|
|
According to standard |
EN
61643-11:2012, IEC 61643-11:2011 |
|
|
ETIM Class |
EC000942 |
|
|
Customs tariff number |
85363010 |
|
|
EAN |
8595090567400 |
Dimensions:
Datasheet:
Module of surge ,6 A, installation C Low
