Type of SPD

T2,T3

Nominal voltage

U_n

230 V AC

Maximum operating voltage

U_c

320.00 V AC

Nominal load current

I_L

10.000 A

Type of network

TT|TN

Maximum overcurrent protection

32 A gL/gG or C 32 A

Short-circuit current rating

I_SCCR

3.0 kA

Residual current

I_PE

0.004 mA

Nominal discharge current (8/20 µs) L-N

I_n

5.00 kA

Nominal discharge current (8/20 µs) N-PE

I_n

5.00 kA

Maximum discharge current (8/20 µs) L-N

I_max

10.00 kA

Maximum discharge current (8/20 µs) N-PE

I_max

10.00 kA

Test voltage L-N

U_oc

10.0 kV

Test voltage L-PE

U_oc

10.0 kV

Test voltage N-PE

U_oc

10.0 kV

Voltage protection level mode L-N

U_p

1.30 kV

Voltage protection level mode L-PE

U_p

1.50 kV

Voltage protection level mode N-PE

U_p

1.50 kV

Response time L-N

t_a

25 ns

Response time N-PE

t_a

100 ns

TOV 5 s L-N

335 V

TOV 5 s L-PE

440 V

TOV characteristic (TOV 5 s)

withstand

TOV 120 min L-N

440 V

TOV characteristic (120 min)

withstand

TOV 200 ms L-PE

1 455 V

TOV 200 ms N-PE

1 200 V

TOV characteristic (TOV 200 ms)

safe failure

Cross-section of connected conductors solid (max)

2.50 mm²

Cross-section of connected conductors stranded (max)

1.50 mm²

Fault indication

loss of voltage, dark grey indication field

Degree of protection

IP 20

Range of ambient temperatures (min/max)

-40 / 80 °C

Humidity

5 - 95 %

According to standard

EN 61643-11:2012, IEC 61643-11:2011

ETIM Class

EC000942

Customs tariff number

85363030

EAN

8595090562443
