Type of SPD

T3

Mounting

installation box

Nominal voltage

U_n

230 V AC

Maximum operating voltage

U_c

275.00 V AC

Type of network

TN

Maximum overcurrent protection

B 16 A

Short-circuit current rating

I_SCCR

1.5 kA

Nominal discharge current (8/20 µs) L-N

I_n

3.00 kA

Nominal discharge current (8/20 µs) N-PE

I_n

3.00 kA

Test voltage L-N

U_oc

6.0 kV

Test voltage N-PE

U_oc

6.0 kV

Voltage protection level mode L-N

U_p

1.35 kV

Voltage protection level mode L-PE

U_p

1.50 kV

Voltage protection level mode N-PE

U_p

1.50 kV

Response time L-N

t_a

25 ns

Response time N-PE

t_a

100 ns

TOV 5 s L-N

335 V

Fault indication

open contact

Remote indication

potential-free open contact

Remote indication contacts

230V/0,5A AC,24V/0,5A DC

Degree of protection

IP 20

Range of ambient temperatures (min/max)

-40 / 80 °C

According to standard

EN 61643-11:2012, IEC 61643-11:2011

ETIM Class

EC000942

Customs tariff number

85363010

EAN

8595090519164
