It is the multipair for the ambitious studio professional who dislikes to compromise on linearity and shielding. For the perfect sound the two opposite wires (“crossover“) are paired. That way we achieve an incredibly low capacitive value of approx. 37 pF wire/wire, and thus an almost loss-free transmission even with excess distances. When connected crosswise the SC-Pegasus CMCK is even digital-capable (AES/EBU 110 Ω)!
Advantages:
- Homogenous, linear sound image
- Low-loss transmission and perfect shielding
- Absolutely superb technical and electrical data
- Digital-capable (with crossover connection!)
Application:
- Ultimate studio reference
- High-quality permanent installation
- Construction of high-end stagebox systems
Properties:
|
Article
number: |
100-0501-04 |
|
Name: |
SC-Pegasus
CMCK04 |
|
EAN: |
4049371050906 |
|
Construction: |
[04(4LI2Y0,20mm²)(ST)DY]CY |
|
Jacket
Ø [mm]: |
15,40 |
|
Jacket
Ø ["]: |
0.6063 |
|
Number
of Channels (audio): |
4 |
|
Inner
conductor: |
8 |
|
Inner
conductor (AES/EBU, DMX): |
8 |
|
Weight
per 1 m [g]: |
295 |
|
Weight
at 1000 ft. [lbs]: |
198.5102 |
|
Fire
load per m [kWh]: |
1,15 |
|
Width
[mm]: |
15,4 |
|
Width
["]: |
0.6063 |
|
Height
[mm]: |
15,4 |
|
Height
["]: |
0.6063 |
Cable Studio 4x4x0.20sqmm Pegasus PVC Black.
