Application:
- FTTH Telecommunication network.
- Premise application for FTTH.
- Local Area Network.
Feature & Benefit:
- Environmentally sealed outer door secured terminations.
- Locking available on front panel.
- Inter connecting for up to 48core.
- Available to use 15mm loose cable.
- Small and compact design.
- Durable and scratch resistant.
- Wall / Pole mounting bracket for easy installation.
- UV protection.
Specification:
|
Model Name |
OTB-48 / Wall / Pole |
|
Max. Capacity / Adaptor type |
48 Core / SC, LC |
|
No. of Input Cable / Output Cable |
6 Port (4+2 Rubber Gasket) |
|
Size(WxHxD) |
420 × 350 × 135 (mm) |
|
No. of Splitter |
1x32 ea or without splitter |
|
Weight |
3.0kg |
|
Material |
ABS |
|
IP Grade |
IP65 |
|
Part Number |
Remark |
|
OTB-48-LC |
LC duplex adaptor 24ea with Box |
|
OTB-48-SC |
SC simplex adaptor 48ea with Box |
ODF Wallmount 24F(2P), W/LC 12 Dpx Adaptors,24 Pigtails.
