Features:

• Polyurethane infused sealing/gasketing system provides EN 60529 IP65 protection covers indicatively Nema 250 classifications 3, 3S, 4, 4X, 5, 12, 12K, 13.
• Three point locking system rods supporting IP protection class Anti-vandalism tested according to DIN V ENV 1630. WK2 Anti-vandalism tested lock handle DIN V ENV 1630 burglar resistance. Test methods for the determination of resistance to manual burglary attempts. *** 9U height has single point lock.
• Internal layer t:1,00 mm thickness and Inner cover/door t:1,5 mm thickness material varies as per your MTRL selection. Inner cover/door protects the enclosure from wind effects and prevents against dust and provided additional protection if the main door is not locked properly. It has ‘’O’’ type barrel locking.
• Open/close function canopy H 70 mm, hiding and securing fan module, helping EN 60529 IP protection, allowing heat dissipation from exhausted hot air through fan kit, hinged , site implementation friendly. This housing may be closed with dummy plate once an air conditioner or heat exchanger unit is integrated on front door. It has integrated hidden hinged mechanism under the roof canopy for maintenance and service period the canopy can stay open during wind effect.
• Air intake kit, filtered, filter replacement possible with wing nuts toolless operation. Once an air conditioner or heat exchanger is integrated these fresh air inlet panels are sealed with metallic dummy panels.
• Clear U marked, 19’’ vertical mounting rails, 4 pcs, DC01, 6112, electro galvanize coating.
• Cable entry gland plate, with PVC or brass cable entry pats, PG sizes, multiple capacity per usage field, customized in standard 1pcs PG32, 4 pcs PG16 cable entry pats.
• H200 mm plinth for concrete assembly for cable management screwed opening placement in front section.
• Monoblock welded body for stability and mechanical resistance and special flange system for water and dust ingress designed to form together with polyurethane gasketing system allows EN 60529 IP65 protection.
• Ventilation louvers for fresh air intake on outer panels and filtered air entry on inner panels are at different height elevation to provide protection against flood or splashing water.
