Product details:

Abrasion- and cut-resistant for tough handling.
Built for harsh environments.
High tensile strength.
Excellent crush resistance.
Suitable for military data communication.
Wide operating temperature range.
Ready for temporary field deployment.
Glass-yarn layer between jackets for added protection against rodents.

Features:

Rugged, field-ready cable engineered for harsh conditions. It combines abrasion/cut resistance, high tensile strength, and excellent crush resistance with reliable operation across a wide temperature range. Ideal for military data links, temporary deployments, and sites requiring extra rodent protection thanks to a glass-yarn barrier between the jackets.

Specifications:

Fibre Type	G.657.A1, G.657.A2, G.657.B3, OM1, OM2, OM3, OM4
Fibre colour	Blue, Orange, Green, Brown, Grey, White, Red, Black, Yellow, Violet, Pink, Aqua
Buffer diameter	0.9 mm
Buffer material	Polyamide
Buffers colour	Natural-transparent
Strength members	Water-swellable Aramid yarns
Inner jacket material	UV resistant, Flame-retardant (V-0, UL94) Thermoplastic Polyurethane
Inner jacket thickness	1.1 mm
Inner jacket colour	Black
Dialectric armouring	Water-swellable Glass yarns
Outer jacket material	UV resistant, Flame-retardant (V-0, UL94) Thermoplastic Polyurethane
Outer jacket thickness	1.2 mm
Outer jacket colour	Black
