Specification:

• With 2-pole emergency stop switch for user protection.
• For protecting operating personnel.
• For manually disconnecting consumers in an emergency.
• Phase and neutral conductors are separated safely.
• Switch must be intentionally unlocked to restart.
• Socket rotation: 45°.
• Feed cable: H05VV-F 3G 1.5 mm2.
• Molded right angle plug.

Material/ Finish:

• Housing: closed sheet steel extrusion, zinc-passivated, powder-coated texture.
• plastic parts: Vampamid 6 0024 VO (UL94), recyclable.
• Internal conductor: full-length busbars, brass.

Dimensions:

• Distance between sockets: Compact: 50 mm.
• Height: 101 mm.
• Width of housing: 44.4 mm (= 1 U).
• Feed cable: 2.5 m.

Color combinations:

Final digit of order number .1:

• RAL 7035, light-grey.

Plastic parts:

• RAL 7035, light-grey.

Additionally:

• With 2-pole fault-current switch and circuit breaker.
• Provides a combination of user, overload and short circuit protection.

Load rating:

• 100–240 V AC/16 A.

Supply schedule:

• 1 x socket strip.
• 2 x mounting brackets.
