Specification:

• High-frequency glitches generally occur in switching processes ranging from 100 kHz to 5 MHz. This high-frequency rate overloads the mains frequency and affects adjacent electronic equipment. The mains filter attenuates this high frequency rate.
• The attenuation behavior is harmonized with the typical interference spectrum.
• The mains filter works in both directions: where glitches from the equipment to the socket strip are also filtered from the mains.
• 19" installation option (for length 483 mm).
• Socket rotation: 45°.
• Feed cable: H05VV-F 3G 1.5 mm2.
• Molded right angle plug.

Material / Finish:

• Housing: closed sheet steel extrusion, zinc-passivated, powder-coated texture.
• Plastic parts: Vampamid 6 0024 VO (UL94), recyclable.
• Internal conductor: full-length busbars, brass.

Dimensions:

• Distance between sockets: 50 mm.
• Height: 45.5 mm.
• Width of housing: 44.4 mm (= 1 U).
• Feed cable: 2.5 m.

Color combination:

Final digit of order number .1:

• RAL 7035, light-grey.

Final digit of order number .6:

• housing RAL 2003 pastel orange Plastic parts:
• RAL 7035, light-grey.

Technical data:

• Nominal voltage: max. 250 V AC, 50 Hz.
• Nominal current, max. 16 A.
• Filter compliant with VDE 0565-3 (EN 60939-1).

Supply schedule:

• 1 x socket strip.
• 2 x mounting brackets.
• 2 x 19" mounting brackets (additionally with 19" installation option).

Note:

• Use only at mains frequency 50Hz.
