Specification:

• Standard safety models consist of a combined overvoltage protection/mains filter element.
• Protects against transient overvoltages from the mains, which, for example, are caused by switching machines on and off.
• When critical overvoltages occur, connection to the mains is cut off.
• Once the protective conductor has been triggered, the green function display light is not illuminated. The socket strip can thus no longer be used.
• Basic equipment protection is classified as class 3 (category D).
• For optimal protection, class 1 and 2 (categories B and C) protective equipment must be installed in the building.
• High-frequency glitches are generally caused by switching processes in an operation from 100 kHz to 5MHz.
• This high-frequency rate overloads the mains frequency and affects adjacent electronic equipment. The mains filter attenuates this high-frequency rate.
• The attenuation behavior is harmonized with the typical interference spectrum.
• 19" installation option (for length 483 mm).
• Socket rotation: 45°.
• Feed cable:HO5VV-F 3G 1.5 mm2.
• Molded right angle plug.
• Material/ Finish:
• Housing: closed sheet steel extrusion, zinc-passivated, powder-coated texture.
• Plastic parts: Vampamid 6 0024 VO (UL94), recyclable.
• Internal conductor: full-length busbars, brass.

Dimensions:

• Distance between sockets: 50 mm.
• Height: 45.5 mm.
• Width of housing: 44.4 mm (= 1 U).
• Feed cable: 2.5 m.

Color combination

Final digit of order number .1:

• RAL 7035, light-grey.

Final digit of order number .6:

• housing RAL 2003 pastel orange.

Plastic parts:

• RAL 7035, light-grey.

Technical data:

• Mains voltage: 230 VAC.
• Nominal current: max. 16 A / 10 A.
• Discharge surge current (8/20 s): 10 kA.
• Reaction time: ‹ 25 ns.
• Safety level (at100 A varistor peak current): L with respect to N: ‹ 800 V, L / N with respect to PE: ‹ 1500 V.
• Overvoltage protection.
• Appliance class: Class 3 – as per DIN EN 61643-11.
• Requirement class: Category D as per VDE 0675-6.
• Mains filter: as per VDE 0565 (EN 60939).

Supply schedule:

• 1 x socket strip.
• 2 x mounting brackets.
