Specification:

• The ergonomically shaped front edge ensures optimal working conditions.
• Height variable for exact adjustment to operator and hardware.
• With support arms for direct connection to the side panels.
• Spacious horizontal cable duct, can be accessed via removeable corner panel and folding mechanism.
• Cable duct with integrated C-rail for mount-ing installation components and T-slot for mounting general accessories.
• With side panels which can also be used as workstation end points.

Material / Finish:

• Crosspiece: extruded aluminium, antistatic, powder-coated texture.
• Support arms: sheet steel, antistatic powder-coated texture.
• Worktop: three layer particle board, FP/Y E1 version, fire protection class B2.
• Worktop coating: high pressure plastic laminate.
• Cable duct, horizontal: sheet steel, rolled, antistatic powder-coated texture.

Colour combination:

Final digit of order number .1:

• Worktop: light-grey.
• Metal parts: RAL 7035 light-grey.

Final digit of order number .5:

• Worktop: beech finish.
• Metal parts: RAL 7021 dark-grey.

Load rating:

• 1500 N (static surface load).

Standards:

• DIN 68761 for worktop.
• EN 438 HGS class for high pressure plastic laminate.

Supply schedule:

• 1 Corner panel.
• 1 Worktop support complete with crosspiece.
• 2 Stabilizers and cable duct.
• Mounting material.

How supplied:

• Pre-assembled modules.
