Specifications:

• ESD version for discharging electrostatic charges.
• For utilizing the area above the worktop as storage and functional surface with additional cabling option.
• Worktop height easily adjustable.
• Cable duct integrated in the crosspiece.
• Tiltable 0–10°.
• Worktop thickness: 30 mm.

Material / Finish:

• Superstructure worktop: three layer particleboard, FP / Y E1 version, fire protection class B2, melamine coated (directly coated) veneer, ABS 3mm thick fine textured, matt.
• Cable duct, horizontal: sheet steel, rolled, antistatic powder-coated texture.

Color:

• Superstructure worktop: light-grey.
• Metal parts: RAL 7035 light-grey.

Load rating:

• 750 N (static surface load).

Standards:

• DIN 68761 for superstructure worktop.
• DIN 68765 for direct coating.
• EN 61340 for electrostatic.

Note:

• Caution with use in tilted state; use edge strip to prevent sliding.

Supply schedule:

• 1 superstructure worktop.
• 1 cable duct.
• Mounting material.

How supplied:

• Preassembled modules.
