Specifications:

• ESD version for discharging electrostatic charges.
• The ergonomically formed front edge ensures optimal working conditions.
• Height variable for exact adjustment to operator and hardware.
• With support arms for direct connection to the side pieces.
• Spacious horizontal cable duct, can be accessed via removable corner panel and folding mechanism.
• Cable duct with integrated C-rail for mounting installation components and T-slot for mounting general accessories.
• With side panels which can also be used as workstation end points.

Material / Finish:

• Crosspiece: extruded aluminium, antistatic, powder-coated texture.
• Support arms: sheet steel, antistatic powder-coated texture.
• Worktop: three layer particle board, FP / Y E1 version, fire protection class B2, volume conductive.
• Worktop coating: high pressure plastic laminate.
• Cable duct, horizontal: sheet steel, rolled, antistatic powder-coated texture.

Color combination:

• Worktop: light-grey.
• Metal parts: RAL 7035 light-grey.

Load rating:

• 1500 N (static surface load).

Standards:

• ESD version.
• DIN 68761 for worktop.
• EN 438 HGS class for high pressure plastic laminate.
• EN 61340 for electrostatic.

Supply schedule:

• 1 corner worktop.
• 1 worktop support complete with crosspiece.
• 2 stabilizers and cable duct.
• 1 support foot, can be set for desk heights, 680-760 mm.
• Mounting material.

How supplied:

• Preassembled modules.
